The DIY KIT MK2 features a built-in 3.5-inch IPS touchscreen with AlgoOS, which offers intuitive touch-to-engrave functionality--no need for a computer.
Local warehouse Free Delivery
Free and Fast
After-Sale Service
Lifetime Tech Support
Worry-Free Trial
30-Day easy returns
Warranty
1-Year warranty policy
The Easiest Operation with AlgoOS
Computer-Free
Touch-to-Engrave Convenience
Endless Creativity in the Image Library
Access an endless gallery of designs with the built-in image library, sparking inspiration and simplifying your creative process.
Smooth Operation | Download and Engrave
Effortlessly transfer images to AlgoOS for fast, seamless processing. With support for multiple formats, there’s no need for specialized software.
Instant Setup | Immediate Use
Achieve perfect engraving with a single click—no more trial-and-error or material waste to get the ideal settings.
All You Need at Your Fingertips
Connect to Wi-Fi securely with only your password—no complicated coding. Firmware update is a tap away, and with support for 17 languages, AlgoOS delivers a user-friendly experience for creators worldwide.
Ignite Your Creativity with AlgoLaser App
Explore the Image Library
Type Any Text You Desire
Create Custom Puzzle Pieces
Design Your Own Drawings
Choose from 37 Types of Materials
(with preset parameters)
Unlock All Materials.
For Daily & Business Needs
- Wood
- Leather
- Glass
- Acrylic
Empowered Software for Your Seamless Workflow.
AlgoLaser App
Monitor and control your machine and access our advanced features anytime, anywhere.
Requires iOS 11.0 or above
Requires Android 7.0 or above
Lightburn
See What the Experts Say!
My 3D Print Lab
WIN A DIY MK2 Laser Engraver: 3D Printing + Lasers = AWESOME!
Figure Feedback
Laser Engraving Made Easy With The Algolaser DIY Kit MK2
Frequently asked questions
Have questions? We’re here to help
What materials can be engraved or cut by AlgoLaser DIY KIT MK2?
Cutting Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather.
Engraving Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather, glass, ceramics, tiles, aluminum oxide, stainless steel, coating metal materials, darkstones.
What is the laser power of DIY KIT MK2 machine?
Can be equipped with 5W, 10W and 20W power modules.
Is DIY KIT MK2 compatible with rotary roller, smart enclosure and smart camera?
Yes, the DIY KIT MK2 is completely compatible with above accessories.
Can DIY KIT MK2 engrave on stainless steel?
Yes, DIY KIT MK2 20W support engraving over 500 shades of color on stainless steel material.
What are the dimensions and working dimensions of the DIY KIT MK2 laser engraving machine?
The size of the entire machine is 601.5mm×668.5mm, and the working area is 400×435mm.
In addition to screen control, can I control it through other devices?
It can also be controlled through PC software and mobile phone software, without even connecting cables, it can be controlled directly through WiFi.
Will machine engraving be interrupted?
Normal work will not be interrupted. If an emergency occurs, such as the power is disconnected, the machine has a power-off resume function.
Product Specifications
Machine
DIY KIT MK2 10W
DIY KIT MK2 5W
Laser Power
10W
5W
Working Space
400mm*435mm
400mm*435mm
Max. Working Speed
12000mm/min
12000mm/min
Laser Source
Diode Laser
Diode Laser
Laser Spot
0.05*0.1mm
0.04*0.09mm
Laser Head Life
>10000 Hours
>10000 Hours
Laser Wavelength
455±5nm
455±5nm
Support File
jpg, svg, png, bmp, G code, dwg
jpg, svg, png, bmp, G code, dwg
Support Systems
Android / iOS / iPad / Windows / macOS
Android / iOS / iPad / Windows / macOS
Software
AlgoLaser APP / Lightburn / LaserGRBL
AlgoLaser APP / Lightburn / LaserGRBL
Product Size
668.5mm*601.5mm*178mm
668.5mm*601.5mm*156.5mm
Product Weight
4.74kg
4.43kg
Input Voltage
100-240~50/60Hz
100-240~50/60Hz
Output Voltage
24V4A（6A MAX）
24V2.5A（6A MAX）
Security Certification
FCC / CE / RoHS / FDA / UL Reports
IEC60825-1/IEC60825-4
FCC / CE / RoHS / FDA / UL Reports
IEC60825-1/IEC60825-4
Learn More About DIY KIT MK2
DIY KIT MK2 material engraving and cutting parameter table setting file
What are the machine size and maximum engraving size of the DIY KIT MK2?
The machine size is 668.5*601.5mm, and the maximum engraving size is: 400*435.
What materials can the DIY KIT MK2 engrave and cut?
Cutting Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather.
Engraving Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather, glass, ceramics, tiles, aluminum oxide, stainless steel, coating metal materials, darkstones.
What are the functional advantages of AlgoOS in DIY KIT MK2?
AlgoOS comes with a resource library, including image and models, and it is able to perform engraving and cutting work independently.
AlgoOS can save images and vector graphics. There is no learning cost. Just select the visual engraving effect and lay down the corresponding materials to complete the work.
How many control software does the DIY KIT MK2 have? How long does it take to learn them?
DIY KIT MK2 supports AlgoOS's direct control work with built-in touchscreen, PC version software (window, mac, Linux), and mobile phone APP connection (IOS, Android)
Documentation
User Manuals
Firmware Download & Support
Downloads
Destktop Computer Software
Below you will find the links to download the latest version of the software. Make sure to always use the installers from the correct source and keep your software updated.
Below you will find the links to download the latest version of the software. Make sure to always use the installers from the correct source and keep your software updated.
Software
Profiles
LightBurn Profile
Ready to import Lightburn Profile for AlgoLaser Delta.
1. Download file
2. In Lightburn – Click Devices in Laser Panel
3. Click Import
4. Browse to the file you downloaded.
5. Click Open
Your AlgoLaser Delta will be imported to Lightburn Devices.
