Super Easy Engraving-Just Like Using Phone

① Built-in Algo Graphics Engine can quickly handle images for engraving. 30s, process a 5M JPG image

② Operate independently, No need for Lightburn & LaserGRBL.

Only 3 steps: Select file; Set parameters; Start engraving.

The Room for More ldeas

Save 8000 design files(4MB) at least

32GB Internal storage.

Without worrying about memory constraints affecting your creative progress or quality.

Powerful Performance

Dual-core CPU* 2

Optimized for smooth transmission of large-scale engraving imagesand intricate graphic processing.

lmage Formats, No Sweat!

Multi-Format lmage Ready

lmage format support jpg. png. bmp, svg

Gcode document format support nc, gcode, gc

Goodbye to Interrupted Creation

Always 100%

Interrupted From Recovery: With AlgoOS, engraving can continue even after an interruption, so that materials are not wasted and time is not lost in cases like：

Unwarranted Interruptions

Emergency Stop

Machine Shutdown

(*Pls enable this function before engraving)

Easy to Start Again

Instant Batch Engraving

1-Click Batch Engraving:

After completing your first work, simply click "Again" to perfectly meet your batch production needs. Both gift customization and mass production can be readily handled with high efficiency.

One-Tap Precision

Hassle-Free Positioning

Drag for Precise Origin Point

Tap and drag freely on the screen to set the origin point of engraving which reduces repetitive and tedious origin proofreading with less time. For more detailed adjustments, we also provide on-screen buttons.

Engraving Range Preview

Before starting the engraving process, AlgoOS allows you to clearly preview the intended range of engraving in advance, effectively avoiding the inconvenience of incomplete or misaligned engravings.

OTA Upgrades

Stay Current with the Latest

One-Click Upgrade: Effortless OTA Upgrates for Continuous

Performance Boosts, Issue Fixes, New Features,

And Optimized Experience.

More Languages

AlgoOS is available in multiple languages

Ensuring that laser engravers are easily accessible to all users around the world.

High Efficiency

Maximum engraving speed: 12,000mm/min,

which can help handle every scale of work and realize rapid mass production.

Finest Detail with Powerful Laser Module

Featurina advanced spatial coherence technoloay, our Powerful Laser Module boasts a minuscule spot size of only 0.05*0.1 mm

Smaller laser spot and ultra-fine lines enable impeccable details

and precise cutting of materials such as wood and acrylic boards, up to a thickness of 0.5 mm.

Unlock All Materials.

For Daily & Business Needs

Wood
Leather
Glass
Acrylic

Faster, Lager, More Efficient

Support extension kit（single installation, double efficiency）

Maximizing the engraving area from 400x435to 400x880 offers a vastly enlarged workspace, fostering creativity and enhancing productivity for mass production tasks.

Wide Compatibility

Accessory: Adaptable to various accessories of Algolaser smart ecosystem, achieve automatic matching, direct connection.

Other branded accessories, can be connected. (via Smart Hub)

USB, Type-A, Type-C, can be connected.

Your safety, Well Ensured

Equipped with 7 major safety features to ensure your safety during operation.

Laser Class 1: No Smoke, No Odour, No Eye Injury, More Peace of Mind

Higher protection standards.

Safety level increased to class 1,

certified according to IEC 60825-1 standard.

(*Additional purchase required for protective box)

Multi-Software Support

For begginers: Algolaser app is a priority for simple logo and photo engraving.

For pro users: Use Lightburn and LaserGRBL for more delicates work.

Package Contents

A one-stop Solution

For All Possible Upgrades

Empowered Software for Your Seamless Workflow.

AlgoLaser App

Monitor and control your machine and access our advanced features anytime, anywhere.

Requires iOS 11.0 or above

Requires Android 7.0 or above

Lightburn

Frequently asked questions

Have questions? We’re here to help

What materials can be engraved or cut by AlgoLaser DIY KIT MK2?

Cutting Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather.

Engraving Material: All kinds of wood, (but be aware of oily wood or wood with very high resin content, as there is a high risk of fire.) plywood, MDF, cardboard, corrugated board, acrylic board, cork sheet, polycarbonate, Depron foam, non-woven fabric, bamboo chips, leather, glass, ceramics, tiles, aluminum oxide, stainless steel, coating metal materials, darkstones.

Alpha MK2 20W-Engraving and cutting parameter

05-22-2024

pdf⬇

What is the laser power of DIY KIT MK2 machine?

Can be equipped with 5W, 10W and 20W power modules.

Is DIY KIT MK2 compatible with rotary roller, smart enclosure and smart camera?

Yes, the DIY KIT MK2 is completely compatible with above accessories.

Can DIY KIT MK2 engrave on stainless steel?

Yes, DIY KIT MK2 20W support engraving over 500 shades of color on stainless steel material.

What are the dimensions and working dimensions of the DIY KIT MK2 laser engraving machine?

The size of the entire machine is 601.5mm×668.5mm, and the working area is 400×435mm.

In addition to screen control, can I control it through other devices?

It can also be controlled through PC software and mobile phone software, without even connecting cables, it can be controlled directly through WiFi.

Will machine engraving be interrupted?

Normal work will not be interrupted. If an emergency occurs, such as the power is disconnected, the machine has a power-off resume function.

Product Specifications

AlgoLaser DIY KIT Mechanical Frame

Optical Power: 20W/10W/5W

Machine Power: 144W

Power Supply: 24V/6A

Maximum Engraving Speed: 12,000 mm/min

Spot Size: 0.05x0.1mm

Product Size: X601.5*Y668.5*Z178mm

Product Weight: 4.74KG

Laser Head Life Expectancy: >10000 hours

Certification: FCC/CE/RoHS/FDA/UL/IEC60825-1/IEC60825-4

Warranty: 12 Months

Safety Features: Laser Emission protection, USB Disconnection Detection, Emergency Stop Button, Child Lock, Current and Voltage Detection, Machine Offset Detection, Machine Tilt Detection

Software and Connection

System Supported: Android, iOS, Windows, Mac OS, Web-based

Control Software: AlgoLaser App / LightBurn/LaserGRBL

Compatible Accessories: 20W laser module, Motorized Z-axis, Engraving Platform, Fireproof Box, Rotary Chuck, Rotary Roller

File Format Supported: JPG, SVG, PNG, BMP, G-code, CAD, AI, CDR, DWG, etc.

Laser Head - AlgoLaser 10W - ALM-10BDU

Laser Module Size: 43.5mm*43.5mm*173.7mm

Laser Module Weight: 365±5g

Optical Power Output: 10W

Laser Output Wavelenght: 455±5nm

Focal Distance: 5 mm (From the Bottom of The Shell)

Spot Size: At 3% power: X 0.06mm - Y 0.05mm, At 100% power: X 0.16mm - Y 0.14mm

Spot Shape: Square

Operating Frequency: <30KHz

Operating Temperature: -10ºC - +45ºC | 14ºF - 113ºF

Life Expectancy: >10,000 Hours

Optical Lense Material: Professional focusing optical glass (quartz glass), Multiple Optical Lens Assembly

Packaging

Box Size: 140mm*240mm*645mm

Net Weight: 4.74kg - 17.2 Pounds

Gross Weight: 5.4kg - 19.18Pounds

Learn More About DIY KIT MK2

DIY KIT MK2 material engraving and cutting parameter table setting file

DIY KIT MK2 5W material engraving and cutting parameter table setting file

pdf⬇

DIY KIT MK2 10W material engraving and cutting parameter table setting file

pdf⬇

DIY KIT MK2 20W material engraving and cutting parameter table setting file

pdf⬇

Documentation

User Manuals

AlgoLaser DIY KIT MK2 - Quick Start Guide (EN)

29-07-2024

pdf⬇

Firmware Download & Support

Downloads

Destktop Computer Software

Below you will find the links to download the latest version of the software. Make sure to always use the installers from the correct source and keep your software updated.

Software

LightBurn Software

Windows / Linux / MacOs

Download PAGE

LaserGrbl
Windows
Download PAGE

Profiles

LightBurn Profile
Ready to import Lightburn Profile for AlgoLaser Delta.
1. Download file
2. In Lightburn – Click Devices in Laser Panel
3. Click Import
4. Browse to the file you downloaded.
5. Click Open
Your AlgoLaser Delta will be imported to Lightburn Devices.

USB Profile
