Super Easy To Use
The World's First Smart Laser Engraver
The world's first fully offline smart laser engraving machine
Super Easy to Use
Instant Image Engraving
Offline Batch Cutting
The 2nd COS Optical Technology
Adopting the advanced second-generation COS technology, the polarized beam combination improves the performance of the laser beam by 40%. Compared to regular 20W laser modules, COS technology compresses the laser spots from a rectangle to a square having a near 1:1 ratio on both low (3%) and high power (100%).
Make your projects stand out with vibrant and durable colors created by oxidation of stainless steel material while engraving.
Artwork with 500+ Shades of Color
Incredible Cutting Ability
Super powerful 22W laser module handles various material thicknesses for cutting easily.
Faster Engraving Speed 500mm/s!
12X faster! Allowing you to complete projects in record time without sacrificing quality.
More Powerful Motherboard
Self-Developed Firmware
Unparalleled accuracy achieved.
Magnetic and Detachable Laser Metal Cover
It's easy to clean and allows you to utlize a deeper cutting focus without the cover.
Semi-Automatic Focus
lnnovative patented design for instant rebound, ensuring pristine engraving results.
Laser Protective Lens Integrated within
Air Assist Nozzle
Effectively protects the laserand prolongs the laser's service life
Dual-Side Fixture Structure
The structure changes the dot cantactingto a complete surfoce contacting, allowing heavierbearing and much less zigzogs when engraving
New Nylon Rollers
7”24hnon-stop operation with unparalleled
durability - surpasses regular rollers by 5 times
Your safety
is our
utmost concern.
Included Plug & Play
Smart Air Pump
Pre-assembled structure and simple
installation steps allow you to start the journey with ease.
Assembly Has Never Been So Easy
Empowered software for your seamless workflow.
AlgoLaser App
Monitor and control your machine and access our advanced features anytime, anywhere.
Requires iOS 11.0 or above
Requires Android 7.0 or above
Lightburn
-
US Free DeliveryFrom $0
-
Full RefundFor free return
-
Online PaymentSecure Sytem
-
Online Support24/7 Free Support
Our results speak for themselves.
"The AlgoLaser Delta 22W laser engraver shines with its advanced tech, user-centric design, and unmatched speed and precision."
"Whether casually personalizing gifts or launching a 3D printing/laser-cutting Etsy shop, the AlgoLaser Delta looks positioned to empower self-sufficient creativity like never before at an astoundingly affordable price. For that reason alone, it earns my strong recommendation."
"When contemplating the future of engraving, one thing becomes evident: with innovative machines like the AlgoLaser Delta at our disposal, there are unlimited possibilities awaiting us."
"Looking to take your crafting and personalization game to the next level? Say hello to the AlgoLaser Delta 22W Laser Engraver!"
"The AlgoLaser Delta 22W Laser Engraver is transforming engraving! AlgoLaser Delta 22W blends touch technology with laser engraving for your desk. The embedded touch screen is more than a gimmick—it opens up a world of accuracy, creativity, and unlimited possibilities."
Frequently asked questions
Have questions? We’re here to help
What does Delta's Smart mean?
Delta's Smart is mainly reflected in the following aspects:
1, Touch screen: Instant engraving and batch cutting off-line, more user-friendly.
2, Smart laser module(Lens Cleaning Reminder,Flame Detective,Air Pressure Monitoring)
3,Plug& play accessorry( Rotary roller, Rotary chuck)
Is it easy for green hand to use Delta laser engraver?
Yes, super easy to use. our latest design focuses on easy of use, like our touch screen.
Also, the machine is pre-assembled, easy to install
Our YouTube channel has instructional videos for you to learn;HTTP://www.youtube.com/@algolaserofficial
Finally, you can get help from Tech Support Team if you have any questions.
For the screen, can do mass production?
yes, you need to transfer to Gcode files from lightburn or laserGRBL
Is this screen fragile?
Honestly, it is fragile, but we will protect it in the package, also will put a fragile sticker on the box, of course, it is better to pay attention when using.
What the difference of Alpha 22W and Delta 22W?
Both are our newest products with the latest module technology, Delta has all-in-one touch screen and it is pre-assembled, super easy to use, Alpha needs to do more complicated assembly, but they have the same 22w laser module,If you are on a low budget you can consider the Alpha 22W, if you want to experience a newer and high performance engraving and cutting progress,you can choose the Delta 22W.
Product Specifications
AlgoLaser Delta Mechanical Frame
Optical Power: 22W
Machine Power: 144W
Power Supply: 24V/6A
Maximum Engraving Speed: 30,000 mm/min
Maximum Motion Speed: 50,000 mm/min
Spot Size: 0.16*0.14mm 100% Power / 0.06*0.05mm 3% Power
Product Size: X650*Y730*Z175mm
Product Weight: 8.5KG
Laser Head Life Expectancy: >8000 hours
Certification: FCC/CE/RoHS/FDA
Warranty: 12 Months
Safety Features: Active Power-Out detection and protection, Laser Over-Exposure Time Limit, USB disconnect shutdown, Emergency stop button, Gyroscope detection,Motherboard over-temperature protection
Software and Connection
System Supported: Android, iOS, Windows, Mac OS, Web-based
Control Software: AlgoLaser App / LightBurn/LaserGRBL
Compatible Accessories: 22W laser module, Motorized Z-axis, Engraving Platform, Fireproof Box, Rotary Chuck, Rotary Roller
File Format Supported: JPG, SVG, PNG, BMP, G-code, CAD, AI, CDR, DWG, etc.
Laser Head - AlgoLaser 20W - LB-20D
Laser Module Size:132mm x 63mm x 60mm
Laser Module Weight:750grams - 1.6 Pounds
Optical Power Output:19.5 to 22W, Average 20W, Acceptable Power Output Variation +5%
Laser Output Wavelenght: 445nm (+-5nm)
Focal Distance: 55 mm (From Module Radiator to Material)
Spot Size: At 3% power: X 0.06mm - Y 0.05mm, At 100% power: X 0.16mm - Y 0.14mm, Click HERE to understand how Spot Size is tested
Spot Shape: Square
Operating Frequency: <30KHz
Operating Temperature: -10ºC - +40º | 14ºF - 104ºF, Multiple Optical Lens Assembly
Diodes Input Voltage: 8.60 Volts
Diodes Inpute Current: 3.8 Amps
Harness Specification: Data Line 4x 26AWG - 0.14 (mm2 cross-sectional area), Laser Line 4x 22AWG - 0.34 (mm2 cross-sectional area)
Connectors Type: Data Line - PHB 2.0 4Pin, Laser Line -
Life Expectancy: >10,000 Hours
Optical Lense Material: Professional focusing optical glass (quartz glass), Multiple Optical Lens Assembly
Packaging
Box Size: 230mmx250mmx710mm
Net Weight: 5.00kg - 11 Pounds
Gross Weight: 6.50kg - 14.3 Pounds
Learn More About Delta
Delta Cutting performance
Best One-Pass Cutting Material and Thickness
10mm Birch Plywood
12mm Basswood Plywood
5mm Eucalyptus plywood
30mm Pine Board
15mm Paulownia Plank
10mm White Oak
5mm MDF
10mm Black Acrylic
3mm Yellow Acrylic
5mm Red Acrylic
3mm Gray Cardboard
0.17mm Stainless Steel Plate
10mm Bamboo
Max Cutting Thickness
12mm Birch Plywood / 3
20mm Basswood Plywood / 15
15mm Eucalyptus plywood / 6
20mm Paulownia Plank / 3
45mm Black Acrylic / 15
8mm Green Acrylic / 6
10mm Red Acrylic / 6
12mm MDF / 6
6mm Gray Cardboard / 2
20mm White Oak / 5
Delta Video
Algolaser Delta 22W Laser Engraver Tutorial
AlgoLaser Delta 22W Assembly Video Guide
Youtube Review Videos
Discover more about Delta from Youtubers
AlgoLaser Delta User Stories
Please be assured that all the above videos are real using experiences of our customers. Hope these videos will give you useful information about our machines. For more details, please follow us @algolaserofficial
Learn about AlgoLaser other products
Faster, Smarter, Stronger.
Algolaser laser cutters combine impressive power with exceptional safety features, ensuring that anyone can easily unleash their creativity and bring their ideas to life through engraving.
Firmware Download & Support
Firmware
Firmware
Firmware is the code that is written to a memory of your AlgoLaser Motherboard. Firmware is installed directly during manufacturing, however its been constantly improved and updated. Please keep a good eye below to confirm if your machine needs to be updated.
Downloads
Destktop Computer Software
Below you will find the links to download the latest version of the software. Make sure to always use the installers from the correct source and keep your software updated.
Software
Profiles
Ready to import Lightburn Profile for AlgoLaser Delta.
1. Download file
2. In Lightburn – Click Devices in Laser Panel
3. Click Import
4. Browse to the file you downloaded.
5. Click Open
Your AlgoLaser Delta will be imported to Lightburn Devices.
Documentation
User Manuals
The Difference With Alpha
Price
$799
$999
Laser Power
22W
22W
Laser Spot Size
0.16*0.14mm 100% Power
0.06*0.05mm 30% Power
0.16*0.14mm 100% Power
0.06*0.05mm 30% Power
Laser Wavelength
455±5nm
455±5nm
Focal Length
55mm
55mm
Laser Head Life Expectancy
>10000 hours
>10000 hours
Max Engraving Speed
20000mm/min
30000mm/min
Movement Speed
30000mm/min
40,000mm/min
Focus Mode
Auto/Manual
Auto/Manual
Machine Power
144W
144W
Power Supply
24V/6A
24V/6A
Motherboard Version
ALGO_LASER_
V2.1
ALGO_LASER_
V3.1
Working Area
400*400mm
440*415mm
3.5'' IPS Screen
/
✔
Offline Engraving
/
✔
RGB Indicator LightRGB
/
✔
Intergrated Air Pump
✔
✔
Connection Method
TF Card
USB C
Wifi-2.4G
TF Card
USB-A/C
Wifi-2.4G/5G
U Disk
Software Supported
LightBurn
LaserGRBL
AlgoLaser App
LightBurn
LaserGRBL
AlgoLaser App
File Format Supported
JPG
SVG
PNG
BMP
G-code
CAD
AI
CDR
DWG, etc.
JPG
SVG
PNG
BMP
G-code
CAD
AI
CDR
DWG, etc.
System Supported
Android
iOS
Windows
Mac OS
Web-based
Android
iOS
Windows
Mac OS
Web-based
Working Temperature
-15°C ~ 30°C
-15°C ~ 30°C
Product Weight
5KG
8.5KG
Product Size
X585*Y674
*Z200mm
X650*Y730
*Z175mm
Packing Weight
9.62KG
12.0KG
Packing Size
870*290*280mm（with pump）
795*720*145mm
Certification
FCC
CE
RoHS
FDA
FCC
CE
RoHS
FDA
Warranty
12 Months
12 Months
